10MM 1250VDC 102uF CBB Polypropylene Film Capacitor

Name: 10MM 1250VDC 102uF CBB Polypropylene Film Capacitor
Brand: GDHY
Price: 0.1 USD

Brand Name : GDHY

Model Number : CBB28-102J1250V-10RN-2R

Certification : SGS,ISO

Place of Origin : GUANGDONG, CHINA

MOQ : 30KPCS

Price : 0.1 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS/ MONTH

Delivery Time : 14 DAYS

Packaging Details : PAPER CARTON

PLACE OF ORIGIN : GUANGDONG, CHINA

TYPE : polypropylene film capacitor

RATED DC VOLTAGE : 1250VDC

MATERIAL : Polypropylene Film

OPERATION TEMPERATURE : -40 ℃～85℃, Tmax+105℃

SUPPLIER TYPE : ORIGINAL MANUFACTURER

MODEL : CBB28-102J1250V-10RN-2R

COLOR : Red

APPLICATION : Suitable for filtering, coupling, bypass, temperature compensation, step-down circuit, timing circuit, industrial instrument, and automatic control system

DIMENSION : 14.5MM *10MM*6MM

TOLERANCE : ±5%;±10%;±20%

ENCAPSULATION : plastic package, Sealed with epoxy resin

CAPACITANCE : 102nF

PITCH : 10MM

Terminals : Clip

CHARACTERISTICS : Metal plastic package, Sealed with epoxy resin

OEM/ODM : OEM/ODM

Contact Now

1250VDC 102uF Metallized Polypropylene Film Capacitor New And Original

Technical Parameter

Reference Standards	GB/T 10190 (IEC 60384-16)
Climate Category	40/85/21
Operating Temperature Range	-40℃~85℃, Tmax 105℃
Capacity Range	0.001uf-2.2uf
Rated Voltage	100VDC,250VDC,400VDC,630VDC,
Capacity Tolerance	±5%(J);±10%(K);±20%(m)
Withstand voltage	Vt-t:1.6Un 5S (at 20±5℃)
Insulation Resistance	R C≥3000s；at 100VDC;25℃ ±5℃,60s

Application

Our products are widely used for lighting industry, audio industry ,automation industry,
power supply,telecommunication industry and the household appliance.

Features

Self healing characteristics, long life.
Wide capacitance range, compact size, light in weight
High stability of temperature vs. Cap. And tanδ
High density thermosetting epoxy resins enhance body and humidity resistance.
Excellent performance be used in by-pass in by-pass, coupling and R.F. circuit.
