2.2UF High Voltage Snubber Capacitor

Product Categories

Conduction Cooled Capacitor [44]
High Frequency Capacitor [13]
MKP X2 Capacitor [26]
Axial Audio Film Capacitor [19]
CBB Polypropylene Film Capacitor [94]
Power Film Capacitor [33]
Polyester Film Capacitor [16]
Water Cooled Capacitor [31]
Induction Heater Capacitor [7]
IGBT Snubber Capacitor [17]
Resonant Capacitor [33]
DC LINK Film Capacitors [28]
CL21 Capacitor [7]

Guangdong Huayu Electronic Company Limited

Contact Now

2.2UF High Voltage Snubber Capacitor

Name: 22UF High Voltage Snubber Capacitor
Brand: GDHY
Price: 1.8 USD

Brand Name : GDHY

Model Number : C31701225JPC1-01

Certification : ISO,SGS

Place of Origin : CHINA

MOQ : 50PCS

Price : USD1.8

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 1000PCS/MONTH

Delivery Time : 14DAYS

Capacity : 2.2uF

Voltage : 700VDC

Size : 42.5*28*37MM

Application : IGBT,UPS, inverter, induction heating, electric welding machine

Model : C31701225JPC1-01

Brand : GDHY

Packing : Plastic Case

Terminal : Copper Sheet

Capacity Tolerance : ±5%(J); ±10%(K)

Material : Polypropylnen Film

Series : Resonant Capacitor

Place Of Original : China

Color : Gray

Encapsulation : Flame Retardant Epoxy encapsulation

ESR : Low

Contact Now

C31 2.2UF 700VDC Snubber Capacitor for IGBT High Voltage Snubber Capacitor

Technical Parameter

Reference Standards	IEC61071 .GB/T17702
Operating Temperature Range	-40℃~+85℃ (Max. +105℃)
Capacity Range	0.047μF -10μF
Rated Voltage	700 VDC -3000VDC
Capacity Tolerance	±5%(J); ±10%(K)
Withstand voltage	1.5Un Dc/10S
Dissipation Factor	tgδ≤0.0005 C≤1μF f=10KHz Tgδ ≤ 0.0010 C≥1μF f=10KHz
Insulation Resistance	C≥0.33μF Rs≥30000MΩ(at20℃ 100VDC 60S) C>0.33 μF RsC≥10000S (at20℃ 100VDC 60S)
Flame Retardation	UL94V-0
Life Expectancy	100000hrs at Un and 85℃

Application

*IGBT buffer absorption circuit protection; IGBT buffer absorption device.

*Widely used in power electronic equipment UPS, inverter, induction heating, electric welding machine and other equipment peak voltage, peak current absorption protection

Features

● Plastic shell, flame-retardant epoxy encapsulation

● Tinned copper sheet extraction

● Resistance to high voltage, low dissipation factor

● Low ESL, low ESR, low temperature rise

● High pulse current, high dV/dt affordability

Product Picture
